Tripp Lite SMART1200LCD 1200VA Smart UPS Battery Back Up, 700W Rack-Mount/Tower, 8 Outlets, LCD Display, AVR, USB, DB9 2URM
Original price was: $391.00.$351.90Current price is: $351.90.
- Brand TRIPP LITE.
Battery Cell Composition Lead Acid. - Voltage 24 Volts.
Color Black. - Material other.
Tripp Lite 1200VA Smart UPS Battery Back Up, 700W Rack-Mount/Tower, 8 Outlets, LCD Display, AVR, USB, DB9 2URM, 3 Year Warranty
- Work though short blackouts & maintain a network connection/ save files safely during longer blackouts: 1200VA/ 700W smart LCD battery backup Uninterruptible power supply (ups) provides up to 12 min Of half-load runtime/ 4 min Of full load runtime
- 8 outlets protect small servers, desktops & all peripherals: 8 outlets provide ups power backup & surge protection (for small server, desktop, monitor, LCD, network workstation, Audio/video components, media center, keyboard, external hard drive, wireless router, iot device)
- Avr corrects brownouts & overvoltage’s without using battery power: otherwise known as automatic voltage Regulation, This conserves battery power for critical blackouts. Also features Tel/DSL/Ethernet protection.
- Free management software/ Rack-mount or tower installation: USB port & free software enable unattended system shutdown and power management. Rack-mount or tower installation form factor allows for use with various applications
Key Specifications
- Model: SMART1200LCD
- Load Capacity: 1200 VA (700 W)
- Nominal AC Input/Output: 120 V, 60 Hz
- AC Outlets: 8 x 5-15R
- Output Waveform (AC Mode): Sine Wave
- Output Waveform (Battery Mode): PWM Sine Wave
- Input Cord: 6 ft. (1.8 m) Cord with 5-15P Right-Angle Plug
- Half-Load Runtime: 12 min. (350 W Load)
Line-Interactive Rack/Tower UPS with LCD
This line-interactive UPS system protects your valuable equipment from damage, downtime and data loss.
- Battery backup supports equipment during outages
- AVR corrects power sags (brownouts) and overvoltages
- Surge protection blocks harmful transient voltages on AC, phone and network lines
- LCD screen displays input voltage, battery capacity and operating status
- USB and serial ports connect to computers for power management and automatic file saves
- 2U rack/tower cabinet supports versatile placement options to match your application
- 3-year warranty and insurance reflect Tripp Lite’s commitment to product quality and customer satisfaction
Power Protection and Battery Backup
Between severe weather, the aging electrical grid and hazards lurking inside your own walls, your equipment is under constant attack from power problems. Even a brief loss of power or a momentary surge can ruin your equipment and destroy irreplaceable data. Prevent damage, downtime and data loss by installing this UPS system. It conditions incoming AC power, provides enough battery backup to outlast most outages and automatically saves open files and shuts down computers gracefully during extended blackouts.
Common Applications
Protect Home and Office Computer Systems: Desktop Computers, Workstations, Displays, Inkjet Printers, Hubs, Scanners, External Drives.
Protect Home and Office Electronics: HDTVs, DVRs, Video Game Consoles, Sound Systems, Streaming Media Players, Chargers.
Protect Servers and Network Equipment: Small Servers, Network-Attached Storage, Network Switches, Wireless Routers, Broadband Modems.
Supports 2U Rack Mounting and Vertical Tower or Horizontal Desktop Placement.
Reliable Battery Backup
– Half-Load Runtime: This UPS system will support a 50% load (350 W) for up to 12 minutes.
– Optimized Outlet Layout: Select outlets have extra-wide spacing to accommodate bulky AC adapters without blocking adjacent outlets.
AVR and Surge/Noise Protection
In locations with chronic voltage problems, frequent switching to battery drains reserve power and shortens battery life. This UPS system has a feature called automatic voltage regulation (AVR) that solves the problem. The UPS detects when input voltage is out of bounds and corrects it without using the battery.
All Tripp Lite UPS systems also include built-in surge protection and noise filtering to shield your equipment from destructive transient voltages and electromagnetic (EMI/RFI) line noise.
Data Line Surge Protection and LCD Screen
Data lines connected to your equipment represent an unlocked ‘back door,’ allowing surges to enter and damage or destroy sensitive electronic components. In addition to protecting against surges on the AC power line, this UPS system protects your equipment against surges on connected phone and network lines.
– The RJ45 jacks protect a phone, analog modem, DSL modem or Ethernet network line.
The illuminated LCD screen shows a variety of helpful data, including input voltage, battery capacity, power status, battery status and AVR status. You can rotate the LCD to match the orientation of the UPS system for optimal viewing, and a built-in dimmer switch adjusts the brightness of the LCD backlight.
Flexible Management Options
There are three ways to manage this UPS system:
1. Use the LCD screen.
2. Use the HID-compliant USB port and your computer’s built-in power management features.
3. Use the USB or serial port with Tripp Lite’s free PowerAlert software.
PowerAlert provides enhanced features like automatic file saves, event notification, logging, advanced device control and an SNMP agent that supports centralized management. You can download the latest version of PowerAlert at Tripp Lite’s website.
Environmentally Responsible Design’
– Recyclable Battery: This UPS system has a recyclable battery, allowing materials to be reprocessed instead of going to a landfill.
– RoHS Compliance: This UPS system complies with the RoHS (Restriction of Hazardous Substances) Directive, limiting the use of hazardous substances in manufacturing.
The SMART1200LCD SmartPro LCD 120V, 1200VA/700W Line-Interactive Uninterruptible Power Supply provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up your desktop computer or audio/visual components, this line-interactive UPS switches to battery backup mode in milliseconds to keep your connected equipment running long enough to save files and shut down safely with no data loss. Eight NEMA 5-15R outlets protect against surges, as well as provide up to 14. 3 minutes of UPS battery support at half load (350W) and 4. 0 minutes of support at full load (700W). Automatic voltage regulation (AVR) corrects severe under voltages as low as 75V and over voltages as high as 147V without using any battery power. EMI/RFI noise filtering improves your equipment’s performance and prevents damage. A 870-joule surge suppression rating protects your equipment from harmful power surges. NEMA 5-15P plug with 6-foot cord connects to any NEMA 5-15R socket. Large rotatable LCD screen shows real-time input voltage, overload, AVR and battery statuses at a glance. Alarm sounds to indicate power loss or low battery. With Tripp Lite’s free Power Alert software (available via free web download), the SMART1200LCD enables safe unattended system shutdown and file saves in case of a prolonged power failure.
